Antivibraciniai produktai
UAB SOLJA rinkai siūlo anti vibracinius demferius, anti vibracines pagalves, amortizacines gumas, gumos amortizatorius ir kitus vibraciją slopinančius elementus.
Taip pat projektuojame ir gaminame nestandartinius SBR, NBR, EPDM gumos, silikono, nitrilo, neopreno, PVC gaminius, įvairias silikono žarnas pagal kliento poreikius
Jeigu Jums reikalinga techninė konsultacija ar domina mūsų produktai, susisiekite su mumis tel. nr.
Jei norite pamatyti visą mūsų produktų asortimentą, apsilankykite el. parduotuvėje.
Pilno mūsų produktų asortimento katalogas su specifikacijomis:
Mūsų siūlomi antivibraciniai produktai
Bobbin Mounts
Hexagon Bobbin Mounts are manufactured with hexagonal end metals to allow the fitter to grip the mounting with a spanner to avoid twisting of the rubber during installation. Mountings can be used in Compression, Shear or a combination of both and can accommodate compression loads from 4kg to 110kg per mounting.
Waisted bobbin mountings are ideal for applications where the predominant force or vibration is in the lateral direction. By design, the waisted bobbins provide a low shear stiffness which provides more deflection and an increased level of vibration reduction in the lateral direction.
Interleaf Mountings are produced with an integrally bonded interleaf metal to increase the compression load capacity of the mounting, and are ideal where large compressive forces need to be accommodated whilst giving relatively small amounts of deflection on the product and also retaining their low stiffness in the shear direction. The mountings are also available without interleaf metals.
Buffers & Bump Stops
Plate buffers provide a Heavy Duty solution for absorbing high levels of shock and impact forces. The large rubber section allows for high levels of deformation, ensuring that the impact energy is dissipated effectively.
Square Plate buffers provide a Heavy Duty solution for absorbing high levels of shock and impact forces. The large rubber section allows for high levels of deformation, ensuring that the impact energy is dissipated effectively.
Truck buffers are designed to absorb shock and impact forces from moving machinery parts, and to protect vehicles from damage whilst manoeuvring.
Conical Buffers are ideal for absorbing shock. They provide high levels of deformation under impact force, and a progressive stiffness rate to accommodate varying shock forces, thus giving excellent levels of absorption and protection of machinery and fabrications.
Captive Transit Mounts
A universal mounting, popular in a wide range of applications. Cost Effective, High Performing and Easy to Install. The rubber is used in shear compression providing optimum performance and offers vibration reduction of up to 95% in all axis. The metal top cap provides protection from contamination such as Oil and Fuel. Load Ratings from 20kg to 5,000kg. Captive Transit Mounts are designed with an integral overload stop to control movement of the mounted equipment, during transit, and also provide a failsafe arrangement to control shock loads. Suitable for both Mobile and Static applications.
Bemag Mounts
Bemag mountings are used primarily within the Construction Industry and can accommodate high dynamic forces. The oversized end metals allows for improve bonded interface between the rubber and metal to increase the fatigue life, particularly where continuous dynamic forces are applied in shear.
Size: 75mm Deep x 160mm Diameter
Stud size: M20 x 45mm Male/Male
Replaces:
- OEM No. 06119395
- BW141AD-2
- BW144AC-2
- BW144AD-2
- BW151AC-2
- BW151AD-2
- BW151ADH-2
- BW154AC-2
- BW154AD-2
- BW161AD-4
- BW170AD
- BW174AD
- BW174AD-2
- BW184AD-2
- BW190AD-4
- BW202AD-4
- BW203AD-4
- BW 141 AD-2
- BW 144 AC-2 AM
- BW 144 AD-2
- BW 144 AD-2 AM
- BW 151 AC-2
- BW 151 AD-2
- BW 151 ADH-2
- BW 154 AD-2
- BW 154 AD-2 AM
- BW 161 AD-4
- BW 170 AD
- BW 174 AD
- BW 174 AD AM
- BW 174 AD AM-2 BW 174 AD-2
- BW 184 AD AM-2
- BW 184 AD-2
- BW 190 AD-4
- BW 190 AD-4 AM
- BW 212 D
- BW 212 D (2A)
- BW 212 D-2
- BW 212 D-2 (2A)
- BW 212 PD
- BW 212 PD-2
- BW 213 D
- BW 213 D (2A)
- BW 213 D US
- BW 213 D-2
- BW 213 D-2 (2A)
- BW 213 DH-2
- BW 213 DH-2 (2A)
- BW 213 PD
- BW 213 PD US
- BW 213 PD-2
- BW 213 PDB
- BW 213 PDB US
- BW 213 PDH
- BW 213 PDH-2
- BW 214 D
- BW 214 D US
- BW 214 PD
Silent Marine Mounts
Silent MarineTM Mountings were originally designed for use in Marine Propulsion Engines and therefore are failsafe and can accommodate thrust. Nowadays Silent MarineTM is popular throughout a wide range industries. Offering a High Performance, Easy to Install, and Cost effective solution to reducing vibration. The mountings provide different stiffness’ in each axis, which provides optimum performance, particularly for Diesel Engines.
Instrument Mounts
Angle Mountings are used in pairs – diametrically opposite to give a low roll frequency and hence improved vibration isolation whilst maintaining good stability of the equipment.
Plate & Pedestal mountings are ideal for lightweight equipment due to their low stiffness. They are available as either a “Plate Mounting” or “Pedestal Mounting” option, and can be made failsafe by fitting top and bottom washers.
High performance mountings for lightweight equipment. They are designed to give high levels of deflection under light loads, providing a low natural frequency and high levels of vibration isolation – both Active & Passive. They can be used in either compression, shear or a combination.
UU Shear mountings are designed to load the rubber in shear and thereby provide a soft vertical spring rate and high levels of vibration absorption. They are also suitable for absorbing shock. They fall within two distinct ranges, those that have zinc plate metals and those that have the metals fully encapsulated in rubber.
Centre Bonded Mounts
Two Piece mountings are an ideal product for reducing vibration and accommodating high shock forces. They are also used to allow flexibility within an installation to reduce stress on brackets and fabrications. Two Piece mountings are suitable for both Static and Mobile applications, and should be installed with top and bottom washers to provide a failsafe installation.
Grommet mountings are normally used as a simple fastening method or to isolate high frequency vibrations. They can be installed in several configurations, such as through brackets or into blind holes, as can be shown in the below Installation diagram.
T-Bushes offer a low cost solution for isolating vibration, reducing structure borne noise, and absorbing shock forces for both mobile & static applications. Using Overload and Rebound washers provide a failsafe installation. The mountings also have the benefit of a low profile height.
Standard Rubber Mounts
Flanged Circular Mountings are a simple, low cost, compression mounting and provide good levels of vibration reduction. The mountings are produced with or without a metal interleaf. The interleaf provides increased load capacity.
Flanged Mountings give high levels of deflection, providing excellent levels of vibration reduction and shock absorption both in the vertical and horizontal planes. They are particularly suited to isolating slow speed equipment.
Turret mountings are designed primarily for the HVAC industry, they are a low cost design, ideal for static applications. The rubber completely encapsulates the metal parts to avoid corrosion problems. They give relatively high levels of deflection, allowing for good levels of vibration reduction to be achieved, even at low running speeds.
Turret mountings are designed primarily for the HVAC industry, they are a low cost design, ideal for static applications. The rubber completely encapsulates the metal parts to avoid corrosion problems. They give relatively high levels of deflection, allowing for good levels of vibration reduction to be achieved, even at low running speeds.
Cone & Cab Mounts
Cone & Cab Mountings are a robust product offering a high horizontal stiffness compared to the vertical stiffness in order to control the movement of Engines, Cabs and Equipment. They are ideal for mobile applications, and are able to accommodate high loads and shock forces whilst offering excellent vibration isolation properties. Cut outs in the rubber section allow for different horizontal to vertical stiffness ratios and the mountings can be supplied with Overload & Rebound washers to provide a failsafe mounting solution. The design of the mountings ensures a low profile installations.
Levelling Feet
Levelling Feet are simple, low cost products suitable for most types of machinery. They allow machinery to be levelled and also provide a degree of vibration and noise reduction. Additional sizes, Stainless Steel Metals, and Oil Resistant/High Temperature rubbers available on request.
Bushes
IOS bushes are manufactured from high quality rubber which is bonded between two concentric sleeves. Designed to allow torsional, radial and axial movement within a system, whilst also offering vibration reduction properties. They are manufactured in such a way as to provide high durability during dynamic loads and prolonged service life. IOS bushings require no lubrication and are maintenance free.
Eccentric Bushes are manufactured from two metal sleeves which are eccentrically offset in the radial direction. This offset allows for a larger proportion of the rubber section to be orientated in the normal direction of load, allowing for relatively large radial deflections to be achieved, whilst maintaining excellent motional control characteristics.
Hangers
Hollow Rubber Springs
Hollow Rubber Springs give high levels of deflection allowing them to provide excellent levels of shock absorption, and are available in a range of styles, sizes and rubber hardness’ to suit each application. Hollow Rubber Springs are typically used as Sole Suspension Springs, Secondary Assister Springs, and Buffer & Bump Stop shock absorbers, and can be used as an alternative to a metal coil spring, where they provide the benefit of increased damping.
Cork Mats
The Vibro-S is a general purpose vibration control pad which is ideal for use in many industrial applications. Vibro-S is formulated to have high endurance even in the most demanding of applications. Conforming to ASTM D297 and ASTM D2240, the Vibro-S is manufactured from high quality cork and Nitrile. Meaning, that even in the presence of oils, fuels or grease, the Vibro-S will not deteriorate.
